Always top of the Class.

Exclusive Comfort

An unprecedented design guarantees maximum functionality and comfort; grouping the information provided to the driver and the controls of the various systems and devices for optimal ergonomics. The reverse shuttle on the steering wheel is also present on the joystick.

Cab Entry

To ensure simple and easy access to the cab, the door of Merlo telehandlers can be opened by up to 180°. In addition, the inside of the door is equipped with a large handrail to help the operator when getting inside and outside of the cab.

Air Conditioning

Developed according to automotive standards, cutting the warm-up and cool-down times in half compared to a conventional air conditioning system. The inlet vent is placed on the side of the cab, away from potential sources of dust and dirt, while inside there are 8 vents.

EPD Eco Power Drive

Maximum savings and efficiency! The Merlo-patented EPD system electronically controls engine and transmission. It manages engine speed, hydrostatic pump flow rate, and hydrostatic drive displacement, maximising efficiency and reducing RPM, saving up to 18% in fuel consumption.

Stabilisers Remaining within Machine Size

Stabilising the machine is essential for safe working. Stabilisers remaining in the outline of the machine allow stabilisation even in the tightest spaces, while also ensuring excellent visibility when travelling. Standard on the entire range of Stabilised telehandlers.

ASCS

The ASCS safety system: the ideal assistant! The system adjusts the speed and maximum extent of the movements based on the attachments in use, the load being handled and its position, thus eliminating the risk of overturning. Standard on the entire range with LS hydraulic system.

Boom Side Shift

Having to reposition the machine, especially after it has already been stabilised, can be a waste of time. Thanks to the boom side-shift, you can pick up or place the load precisely, without any further manoeuvring, for maximum productivity. Standard on the Stabilised, Medium Capacity range in the TT and Panoramic High Capacity models.

P40.17EE Specifications

Name
P40.17EE
Unladen Weight (KG)
11670
Maximum Load Capacity (KG)
4000
Lift Height (M)
16.6
Maximum Reach (M)
12.47
Lift Height at Max. Load Capacity (M)
10.3
Reach at Max. Load Capacity (M)
4.06
Load Capacity at Max. Lift Height (KG)
2500
Load Capacity at Max. Reach (KG)
550
Boom Side-Shift (MM)
+/-435
Frame Levelling (%)
+/-8
Boom Section
4

Name
P40.17EE
Engine
Perkins 904
Range/Cylinder (L)
2.5/4
Engine Power (KW/HP)
55.4/75.1
Anti-Pollution Technology
Tier 3
Reversible Fan
Yes
Maximum Speed (KM/H)
33
Fuel Tank Capacity (L)
140
Hydrostatic Transmission
Yes – 2V
EPD
STD
Electronic Joystick
Yes
Axles
Drop Portal
Reducers
RR 700
Brakes
Dry discs
Automatic Parking Brake
Yes

Name
P40.17EE
Hydraulic Pump
LS
Delivery / Pressure (Bar-L/Min)
108 – 250
Hydraulic Oil Tank Capacity (L)
100
Auxiliary Hydraulic Service on Boom
Yes
rear Service Line
OPT

Name
P40.17EE
Cab Finishing
Standard
ASCS
Light
Fops II Cab
Yes
Rops Cab
Yes
Controls
Electronic Joystick Control
Tilting Cab
No
Reverse Shuttle
Dual Reverse

Name
P40.17EE
Hydropneumatic Suspension CS Merlo
No
Hydropneumatic Suspension BSS Merlo
Opt
Hydropneumatic Suspension EAS Merlo
No
Work Lights on Cab
Opt
Sunshade in the Cab
Opt
Tac-Lock
Yes
Pre-arrangement for Aerial Work Platform
Opt
Two Floating Forks
Yes
Pedal Inching Control
Yes
Permanent Four-Wheel Drive
Yes
All Wheel Steering
Yes
Three Steering Way
Yes
Standard Tyres
400/70-24″
Dpt Tyres
445/80-24″, 445/65-22,5″
Hydraulic Controlled Stabilisers
Narrow
Turret Rotation
No
Tractor Tyre Approval
No
Pneumatic Brakes (TON)
No
Hydraulic Brakes (TON)
No
PTO
3 Point Rear Linkage
