Always top of the class

Exclusive Comfort

An unprecedented design guarantees maximum functionality and comfort; grouping the information provided to the driver and the controls of the various systems and devices for optimal ergonomics. The reverse shuttle on the steering wheel is also present on the joystick.

Cab Entry

To ensure simple and easy access to the cab, the door of Merlo telehandlers can be opened by up to 180°. In addition, the inside of the door is equipped with a large handrail to help the operator when getting inside and outside of the cab.

Air Conditioning

Developed according to automotive standards, cutting the warm-up and cool-down times in half compared to a conventional air conditioning system. The inlet vent is placed on the side of the cab, away from potential sources of dust and dirt, while inside there are 8 vents.

EPD Eco Power Drive

Maximum savings and efficiency! The Merlo-patented EPD system electronically controls engine and transmission. It manages engine speed, hydrostatic pump flow rate, and hydrostatic drive displacement, maximising efficiency and reducing RPM, saving up to 18% in fuel consumption.

180° Opening

A door that made history! Merlo is the only manufacturer to offer a door with 180° split opening. Standard on the entire range.

Ground Clearance

In the field as in the yard, you can not let obstacles stop you. A ground clearance of up to 460 cm allows maximum agility also on uneven terrain.



TF42.7-116EE Specifications

Name
TF42.7-116EE
Unladen Weight (KG)
7700
Maximum Load Capacity (KG)
4200
Lift Height (M)
7
Maximum Reach (M)
3.8
Lift Height at Max. Load Capacity (M)
5.6
Reach at Max. Load Capacity (M)
1.5
Load Capacity at Max. Lift Height (KG)
3500
Load Capacity at Max. Reach (KG)
1750
Boom Side Shift (MM)
Frame Levelling (%)
Boom Section
2

Name
TF42.7-11EE
Engine
Perkins 904J
Range/Cylinder (L)
3.6/4
Engine Power (KW/HP)
85.9/116.8
Anti-Pollution Technology
Tier 3
Reversible Fan
Yes
Maximum Speed (KM/H)
40
Fuel Tank Capacity (L)
140
Hydrostatic Transmission
Yes – 2V
EPD
Plus
Electronic Joystick
Yes
Axles
Drop Portal
Reducers
RR 700
Brakes
Dry discs
Automatic Parking Brake
Yes

Name
TF42.7-116EE
Hydraulic Pump
LS+FS
Delivery / Pressure (Bar-L/Min)
151-250
Hydraulic Oil Tank Capacity (L)
100
Auxiliary Hydraulic Service on Boom
Yes
rear Service Line
OPT

Name
TF42.7-116EE
Cab Finishing
Standard
ASCS
Light
Fops II Cab
Yes
Rops Cab
Yes
Controls
Electronic Joystick Control
Tilting Cab
No
Reverse Shuttle
Dual Reverse

Name
TF42.7-116EE
Hydropneumatic Suspension CS Merlo
No
Hydropneumatic Suspension BSS Merlo
Opt
Hydropneumatic Suspension EAS Merlo
No
Work Lights on Cab
Opt
Sunshade in the Cab
Opt
Tac-Lock
Yes
Pre-arrangement for Aerial Work Platform
Opt
Two Floating Forks
Yes
Pedal Inching Control
Yes
Permanent Four-Wheel Drive
Yes
All Wheel Steering
Yes
Three Steering Way
Yes
Standard Tyres
400/70-24″
Opt Tyres
460/70-24″
Hydraulic Controlled Stabilisers
No
Tractor Tyre Approval
No
Pneumatic Brakes (TON)
Opt
Hydraulic Brakes (TON)
Opt
PTO
3 Point Rear Linkage
