Always top of the class

Exclusive Comfort

An unprecedented design guarantees maximum functionality and comfort; grouping the information provided to the driver and the controls of the various systems and devices for optimal ergonomics. The reverse shuttle on the steering wheel is also present on the joystick.

Cab Entry

To ensure simple and easy access to the cab, the door of Merlo telehandlers can be opened by up to 180°. In addition, the inside of the door is equipped with a large handrail to help the operator when getting inside and outside of the cab.

Air Conditioning

Developed according to automotive standards, cutting the warm-up and cool-down times in half compared to a conventional air conditioning system. The inlet vent is placed on the side of the cab, away from potential sources of dust and dirt, while inside there are 8 vents.

EPD Eco Power Drive

Maximum savings and efficiency! The Merlo-patented EPD system electronically controls engine and transmission. It manages engine speed, hydrostatic pump flow rate, and hydrostatic drive displacement, maximising efficiency and reducing RPM, saving up to 18% in fuel consumption.

180° Opening

A door that made history! Merlo is the only manufacturer to offer a door with 180° split opening. Standard on the entire range.

Implement Recognition

Every implement has its own features. Thanks to the automatic implement recognition system, the ASCS adapts load chart and safety limits to guarantee maximum performance in total safety at all times. Standard on the entire range.





TF35.7-115EE Specifications

Name
TF35.7-115EE
Unladen Weight (KG)
6700
Maximum Load Capacity (KG)
3500
Lift Height (M)
6.5
Maximum Reach (M)
3.5
Lift Height at Max. Load Capacity (M)
6.1
Reach at Max. Load Capacity (M)
1.3
Load Capacity at Max. Lift Height (KG)
3000
Load Capacity at Max. Reach (KG)
1300
Boom Section
2

Name
TF35.7-115EE
Engine
DEUTZ TCD 3.6
Range/Cylinder (L)
3.6/4
Engine Power (KW/HP)
85/115
Anti-Pollution Technology
Tier 3
Reversible Fan
Yes
Maximum Speed (KM/H)
40
Fuel Tank Capacity (L)
85
Hydrostatic Transmission
Yes – 2V
EPD
Plus
Electronic Joystick
Yes
Axles
Axial
Reducers
Epicyclic
Brakes
Dry discs
Automatic Parking Brake
Yes

Name
TF35.7-115EE
Hydraulic Pump
LS+FS
Delivery / Pressure (Bar-L/Min)
125-210
Hydraulic Oil Tank Capacity (L)
85
Auxiliary Hydraulic Service on Boom
Yes
rear Service Line
OPT

Name
TF35.7-115EE
Cab Finishing
Standard
ASCS
Full
Fops II Cab
Yes
Rops Cab
Yes
Controls
Electromechanical Joystick Control
Tilting Cab
No
Reverse Shuttle
Dual Reverse

Name
TF35.7-115EE
Hydropneumatic Suspension CS Merlo
No
Hydropneumatic Suspension BSS Merlo
Opt
Hydropneumatic Suspension EAS Merlo
No
Work Lights on Cab
Opt
Sunshade in the Cab
Opt
Tac-Lock
Yes
Pre-arrangement for Aerial Work Platform
Opt
Two Floating Forks
Yes
Pedal Inching Control
Yes
Permanent Four-Wheel Drive
Yes
All Wheel Steering
Yes
Three Steering Way
Yes
Standard Tyres
400/70-24″
Opt Tyres
460/70-24″
Hydraulic Controlled Stabilisers
No
Tractor Tyre Approval
No
Pneumatic Brakes (TON)
Opt
Hydraulic Brakes (TON)
Opt
